SunRunner™ Cable Clips are designed to provide a better method for PV module wire management. They may be used wherever single or multiple cable management is needed. The robust double-compression design accommodates from (1) 12 gauge USE-2 to (2) 10 gauge PV-1000 solar wires. Also for use with other cables from 0.20"-0.30" (5-7.6mm) in diameter.
Unit of Measure

Specifications

Brands

 N/A SunRunner™

Type

 N/A Cable

Material

 N/A 304 Stainless Steel

Overall Height

 N/A 0.39 in9.9 mm

Material Thickness (Decimal)

 N/A 24 gauge

Footprint Size

 N/A 0.97 x 0.50 in24.6 x 12.7 mm

Number of Wire

 N/A 2

Maximum Wire Size

 N/A 0.20 to 0.30 in5.0 to 7.6 mm

Panel Size

 N/A 0.055 to 1.25 in1.4 to 3.2 mm

Weight

 N/A 1 lb

Features and Benefits

Features and Benefits

 N/A
  • Smooth clip edges prevent damage to cable insulation.
  • Locking tabs securely fasten clips to module extrusions, or other panels.
  • Generous lead-in for installation without tools.
  • Screwdriver slot for easy removal or movement of clips if necessary.
  • Neatly dresses cables on PV panel frames or along mounting channels.
  • Fits module frames up to 0.125" (3.2mm) thick.
  • Constructed from corrosion resistant 304 stainless steel.
