These Align Nuts can overcome panel-aligning problems on fast-moving assembly lines. They snap quickly into position on metal or plastic panels and instantly align with power-driven screws. Because drift pins or forced alignment is not needed, these Align Nuts eliminate delays and the risks of hole/panel damage and expensive scrap loss.
Unit of Measure
Specifications
Screw Size |
N/A M4.2 x 1.41 |
Panel Size |
N/A 1.5 mm3.0 mm |
Throat Distance |
N/A 9.5 mm |
Trade Name |
N/A U-Nut Align Nut |
Features and Benefits
Features and Benefits |
N/A
One-piece and self-retaining, Align Nuts combine stamped fastener convenience and economy with multiple thread strength and reliability. The S-shaped spring steel retainer has generous elongated mounting holes that permit up to 1/4". The trapped sliding member incorporates a patented extruded configuration that provides high torque installation and withstands unusually high clamp loads. Prevailing torque on the screw is inherent in the design. The screw will not loosen due to vibration, panel set or migration. All parts are Spring Steel, heat treated, unless otherwise specified. |
