Heavy duty cable ties offer a higher tensile strength for heavy load applications. The head design guarantees high tensile strength and a low insertion force. The bent tail design allows quick and simple installations by hand. For high volume applications, tensioning tools are available to ensure consistent and safe installation.
Unit of Measure

Specifications

Material

 N/A Polyamide 6.6 (PA66)

Width

 N/A 0.3 in7.6 mm

Length

 N/A 15.2 in387.0 mm

Maximum Bundle Diameter (Decimal)

 N/A 4.1 in105.0 mm

Minimum Bundle Diameter

 N/A 0.2 in5.0 mm

Minimum Tensile Strength

 N/A 120.0 lb535.0 N

Flammability Rating

 N/A UL94 V2 Halogen Free

Small Outside Diameter

 N/A 0.116 in2.9 mm

Operating Temperature

 N/A -40 to +185 ºF-40 to +85 ºC

Industry Standards/Certifications

 N/A Military Standard (MIL 53421) UL ZODZ2.E64139 Underwriters Laboratories (UL) Listed (US and Canada)

Tie Closure

 N/A Plastic Pawl

Variant

 N/A Inside Serrated

Features and Benefits

Features and Benefits

 N/A Heavy Duty Cable Ties offer:
  • Higher tensile strength
  • Head design provides high tensile strength with very low insertion force
  • Bent tail ensures a quick and simple installation
