Single Thread Angle Bracket Bolt Retainers
Shaft & Bolt Retainers
Angle Bracket Bolt Retainers combine the conventional angle bracket with the Spring Nut principle of Spring Tension Fastening to reduce the number of parts, provide structural strength and speed the assembly process.
Item # |
Item Name |
Material Thickness (Decimal) |
Width |
Length |
|---|---|---|---|---|
| 01C19185020 | N/A 0.390 Inch (in) Height Single Thread Angle Bracket Bolt Retainer | Material Thickness (Decimal) N/A 0.020 in | Width N/A 0.310 in | Length N/A 0.450 in |
| 01176046-23Q | N/A 0.390 Inch (in) Height Single Thread Angle Bracket Bolt Retainer | Material Thickness (Decimal) N/A 0.022 in | Width N/A 0.310 in | Length N/A 0.450 in |
| 01C62946Z | N/A 1.100 Inch (in) Height Single Thread Angle Bracket Bolt Retainer | Material Thickness (Decimal) N/A 0.025 in | Width N/A 0.75 in | Length N/A 0.750 in |
| 01C8706832 | N/A 0.390 Inch (in) Height Single Thread Angle Bracket Bolt Retainer | Material Thickness (Decimal) N/A 0.020 in | Width N/A 0.310 in | Length N/A 0.450 in |
| 01C62898Z | N/A 0.740 Inch (in) Height Single Thread Angle Bracket Bolt Retainer | Material Thickness (Decimal) N/A 0.028 in | Width N/A 0.63 in | Length N/A 0.740 in |
| 01C64368Z | N/A 1.310 Inch (in) Height Single Thread Angle Bracket Bolt Retainer | Material Thickness (Decimal) N/A 0.028 in | Width N/A 0.63 in | Length N/A 0.740 in |
| 01C85748Z | N/A 0.740 Inch (in) Height Single Thread Angle Bracket Bolt Retainer | Material Thickness (Decimal) N/A 0.028 in | Width N/A 0.63 in | Length N/A 0.740 in |
| 01C85688Z | N/A 0.740 Inch (in) Height Single Thread Angle Bracket Bolt Retainer | Material Thickness (Decimal) N/A 0.028 in | Width N/A 0.63 in | Length N/A 0.740 in |
| 01C62648Z | N/A 0.740 Inch (in) Height Single Thread Angle Bracket Bolt Retainer | Material Thickness (Decimal) N/A 0.028 in | Width N/A 0.63 in | Length N/A 0.740 in |
| 01C85648Z | N/A 0.740 Inch (in) Height Single Thread Angle Bracket Bolt Retainer | Material Thickness (Decimal) N/A 0.028 in | Width N/A 0.63 in | Length N/A 0.740 in |
| 01C85618Z | N/A 1.310 Inch (in) Height Single Thread Angle Bracket Bolt Retainer | Material Thickness (Decimal) N/A 0.028 in | Width N/A 0.63 in | Length N/A 0.740 in |
| 01C85638Z | N/A 0.750 Inch (in) Height Single Thread Angle Bracket Bolt Retainer | Material Thickness (Decimal) N/A 0.028 in | Width N/A 0.63 in | Length N/A 0.750 in |
| 01C85628Z | N/A 1.310 Inch (in) Height Single Thread Angle Bracket Bolt Retainer | Material Thickness (Decimal) N/A 0.028 in | Width N/A 0.63 in | Length N/A 0.750 in |
| 01C62948Z | N/A 1.100 Inch (in) Height Single Thread Angle Bracket Bolt Retainer | Material Thickness (Decimal) N/A 0.028 in | Width N/A 0.75 in | Length N/A 0.750 in |
| 01C85258Z | N/A 0.560 Inch (in) Height Single Thread Angle Bracket Bolt Retainer | Material Thickness (Decimal) N/A 0.028 in | Width N/A 0.63 in | Length N/A 0.760 in |
| 01157048-01Q | N/A 0.800 Inch (in) Height Single Thread Angle Bracket Bolt Retainer | Material Thickness (Decimal) N/A 0.031 in | Width N/A 0.5 in | Length N/A 0.850 in |
| 01C628910Z | N/A 0.740 Inch (in) Height Single Thread Angle Bracket Bolt Retainer | Material Thickness (Decimal) N/A 0.028 in | Width N/A 0.63 in | Length N/A 0.740 in |
| 01C643610Z | N/A 1.310 Inch (in) Height Single Thread Angle Bracket Bolt Retainer | Material Thickness (Decimal) N/A 0.028 in | Width N/A 0.63 in | Length N/A 0.740 in |
| 01C857410Z | N/A 0.740 Inch (in) Height Single Thread Angle Bracket Bolt Retainer | Material Thickness (Decimal) N/A 0.028 in | Width N/A 0.63 in | Length N/A 0.740 in |
