Capped Washer Type DE and DL Style Locknuts®
Shaft & Bolt Retainers
Capped Washer-Type Locknuts® combine the functionality of a hex nut, lock washer and flat washer for reduced cost and installation time. The washer base can cover larger clearance holes, and the locking design prevents back-off from vibration and thermal stress.
Item # |
Item Name |
Thread Size |
Height |
Flange Diameter |
---|---|---|---|---|
02P604006-03Q | N/A 0.159 Inch (in) Height Capped Washer Type DE and DL Style Locknut® | Thread Size N/A 8-32 | Height N/A 0.159 in | Flange Diameter N/A 15/32 in |
02P604011-06Q | N/A 0.164 Inch (in) Height Capped Washer Type DE and DL Style Locknut® | Thread Size N/A 10-32 | Height N/A 0.164 in | Flange Diameter N/A 15/32 in |
02P604013-06Q | N/A 0.166 Inch (in) Height Capped Washer Type DE and DL Style Locknut® | Thread Size N/A 10-32 | Height N/A 0.166 in | Flange Diameter N/A 1/2 in |
02P604026-00Q | N/A 0.188 Inch (in) Height Capped Washer Type DE and DL Style Locknut® | Thread Size N/A 1/8-27 | Height N/A 0.188 in | Flange Diameter N/A 7/8 in |
02P604026-06Q | N/A 0.188 Inch (in) Height Capped Washer Type DE and DL Style Locknut® | Thread Size N/A 1/8-27 | Height N/A 0.188 in | Flange Diameter N/A 7/8 in |
02P012383-01Q | N/A 0.155 Inch (in) Height Capped Washer Type DE and DL Style Locknut® | Thread Size N/A 3/8-32 | Height N/A 0.155 in | Flange Diameter N/A 5/8 in |
02P012383-03Q | N/A 0.155 Inch (in) Height Capped Washer Type DE and DL Style Locknut® | Thread Size N/A 3/8-32 | Height N/A 0.155 in | Flange Diameter N/A 5/8 in |
02P604040-03Q | N/A 0.155 Inch (in) Height Capped Washer Type DE and DL Style Locknut® | Thread Size N/A 3/8-32 | Height N/A 0.155 in | Flange Diameter N/A 5/8 in |
